Material: Low carbon steel wire Q195 Q235
Processing mode: welded
Panel Classification:
I. Black wire welded mesh + pvc coated;
II. Galvanized welded mesh + pvc coated;
III. Hot dipped galvanized welded mesh + pvc coated.
(PVC coated colors: dark green, light green, blue, yellow, white, black, orange and red, etc.)
Product Specification
| DIMENSIONS (mm) | ||||||
| Fence Height | post height | fence width | bending | wire diameter | mesh | mesh |
| 630 | 1100 | 2500 | 2 | 45 | 200X55 | 150X50 |
| 830 | 1300 | 2 | ||||
| 1030 | 1500 | 2 | ||||
| 1230 | 1800 | 2 | ||||
| 1530 | 2000 | 3 | ||||
| 1830 | 2300 | 4 | ||||
| 2030 | 2500 | 4 | ||||
| 2430 | 3000 | 4 | ||||
